Aclar® Barrier Films
Aclar UltRx 4000 (4.00 Mil/102 μm)
Aclar® UltRx 4000 film is a 4.00 mil (102 µm) PCTFE homopolymer, high performance barrier film for the pharma and medical markets. It thermoforms well on conventional blister packaging equipment and provides the highest barrier of any clear film.
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
Aclar® UltRx 4000 film is a 4.00 mil (102 µm) PCTFE homopolymer, high performance barrier film for the pharmaceutical and medical markets. It thermoforms well on conventional blister packaging equipment and provides the highest barrier of any clear film. Aclar is a clear, poly-chloro-tri-fluoro-ethylene (PCTFE) pharmaceutical packaging film for blister packaging. With Aclar’s superior moisture barrier, your product is protected for worldwide distribution, including Zone 4 tropical locations. All Aclar fluoropolymer films comply with FDA regulation #21 CFR 177.1380, Drug Master File #1578.With Aclar film, you can dial in the exact properties you need from several product grades so you have the optimum balance of performance and economics. When you also need oxygen and/or light barrier protection, Aclar film can be laminated to a wide range of substrates.Honeywell has been supporting the pharmaceutical industry with Aclar film for more than 40 years.Aclar high and ultra-high barrier films are usually selected for the most demanding applications, such as high moisture sensitivity or the need to pass the accelerated stability trials as set forth by ICH.
Specifications
Properties
- Crystalline Melting Point
- 211 °C, ASTM D4591
- 412 °F, ASTM D4591
- Dimensional Stability
- < -5% TD, 10 min at 300 °F/149 °C, ASTM D1204
- <= +5% MD, 10 min at 300 °F/149 °C, ASTM D1204
- Elongation
- 150 - 225% MD, ASTM D882
- 175 - 225% TD, ASTM D882
- Haze
- < 1%, ASTM D1003
- Modulus
- 1103 - 1379 MPa MD/TD Secant, ASTM D882
- 160000 - 200000 psi MD/TD Secant, ASTM D882
- Specific Gravity
- 2.11, ASTM D1505
- Surface Tension
- >= 42 dynes/cm (Treated Side), ASTM D2578
- Tensile Strength
- 28 - 48 MPa TD, ASTM D882
- 4000 - 7000 psi TD, ASTM D882
- 41 - 62 MPa MD, ASTM D882
- 6000 - 9000 psi MD, ASTM D882
- Water Vapor Transmission Rate
- 0.0006 gms/100in²/day at 77 °F (25 °C), 60% RH, ASTM F1249
- 0.0009 gms/100in²/day at 86 °F (30 °C), 65% RH, ASTM F1249
- 0.001 gms/100in²/day at 86 °F (30 °C), 60% RH, ASTM F1249
- 0.0031 gms/100in²/day at 104 °F (40 °C), 75% RH, ASTM F1249
- 0.0042 gms/100in²/day at 100 °F (37.8 °C), 100% RH, ASTM F1249
- 0.009 gms/m²/day at 77 °F (25 °C), 60% RH, ASTM F1249
- 0.015 gms/m²/day at 86 °F (30 °C), 65% RH, ASTM F1249
- 0.016 gms/m²/day at 86 °F (30 °C), 60% RH, ASTM F1249
- 0.048 gms/m²/day at 104 °F (40 °C), 75% RH, ASTM F1249
- 0.065 gms/m²/day at 100 °F (37.8 °C), 100% RH, ASTM F1249
- Yield
- 3,285 in2/lb.
- 4.67 m²/kg
Notes
- Test Conditions
- Test conditions for properties are 73°F, 50% RH unless otherwise noted
Sampling
- Sample Products
- Yes
Properties
- Crystalline Melting Point
- 211 °C, ASTM D4591
- 412 °F, ASTM D4591
- Dimensional Stability
- < -5% TD, 10 min at 300 °F/149 °C, ASTM D1204
- <= +5% MD, 10 min at 300 °F/149 °C, ASTM D1204
- Elongation
- 150 - 225% MD, ASTM D882
- 175 - 225% TD, ASTM D882
- Haze
- < 1%, ASTM D1003
- Modulus
- 1103 - 1379 MPa MD/TD Secant, ASTM D882
- 160000 - 200000 psi MD/TD Secant, ASTM D882
- Specific Gravity
- 2.11, ASTM D1505
- Surface Tension
- >= 42 dynes/cm (Treated Side), ASTM D2578
- Tensile Strength
- 28 - 48 MPa TD, ASTM D882
- 4000 - 7000 psi TD, ASTM D882
- 41 - 62 MPa MD, ASTM D882
- 6000 - 9000 psi MD, ASTM D882
- Water Vapor Transmission Rate
- 0.0006 gms/100in²/day at 77 °F (25 °C), 60% RH, ASTM F1249
- 0.0009 gms/100in²/day at 86 °F (30 °C), 65% RH, ASTM F1249
- 0.001 gms/100in²/day at 86 °F (30 °C), 60% RH, ASTM F1249
- 0.0031 gms/100in²/day at 104 °F (40 °C), 75% RH, ASTM F1249
- 0.0042 gms/100in²/day at 100 °F (37.8 °C), 100% RH, ASTM F1249
- 0.009 gms/m²/day at 77 °F (25 °C), 60% RH, ASTM F1249
- 0.015 gms/m²/day at 86 °F (30 °C), 65% RH, ASTM F1249
- 0.016 gms/m²/day at 86 °F (30 °C), 60% RH, ASTM F1249
- 0.048 gms/m²/day at 104 °F (40 °C), 75% RH, ASTM F1249
- 0.065 gms/m²/day at 100 °F (37.8 °C), 100% RH, ASTM F1249
- Yield
- 3,285 in2/lb.
- 4.67 m²/kg
Notes
- Test Conditions
- Test conditions for properties are 73°F, 50% RH unless otherwise noted
Sampling
- Sample Products
- Yes
- Crystalline Melting Point : 211 °C, ASTM D4591|412 °F, ASTM D4591
- Specific Gravity : 2.11, ASTM D1505
- Modulus : 1103 - 1379 MPa MD/TD Secant, ASTM D882|160000 - 200000 psi MD/TD Secant, ASTM D882
- Haze : < 1%, ASTM D1003
- Elongation : 150 - 225% MD, ASTM D882|175 - 225% TD, ASTM D882
- Surface Tension : >= 42 dynes/cm (Treated Side), ASTM D2578
- Yield : 3,285 in2/lb.|4.67 m²/kg
- Water Vapor Transmission Rate : 0.0006 gms/100in²/day at 77 °F (25 °C), 60% RH, ASTM F1249|0.0009 gms/100in²/day at 86 °F (30 °C), 65% RH, ASTM F1249|0.001 gms/100in²/day at 86 °F (30 °C), 60% RH, ASTM F1249|0.0031 gms/100in²/day at 104 °F (40 °C), 75% RH, ASTM F1249|0.0042 gms/100in²/day at 100 °F (37.8 °C), 100% RH, ASTM F1249|0.009 gms/m²/day at 77 °F (25 °C), 60% RH, ASTM F1249|0.015 gms/m²/day at 86 °F (30 °C), 65% RH, ASTM F1249|0.016 gms/m²/day at 86 °F (30 °C), 60% RH, ASTM F1249|0.048 gms/m²/day at 104 °F (40 °C), 75% RH, ASTM F1249|0.065 gms/m²/day at 100 °F (37.8 °C), 100% RH, ASTM F1249
- Dimensional Stability : < -5% TD, 10 min at 300 °F/149 °C, ASTM D1204|<= +5% MD, 10 min at 300 °F/149 °C, ASTM D1204
- Tensile Strength : 28 - 48 MPa TD, ASTM D882|4000 - 7000 psi TD, ASTM D882|41 - 62 MPa MD, ASTM D882|6000 - 9000 psi MD, ASTM D882
- Test Conditions : Test conditions for properties are 73°F, 50% RH unless otherwise noted
- Sample Products : Yes
