Foam Blowing Agents
Enovate® 245fa
Enovate® 245fa has been the standard in HFC technology for polyurethane foam applications worldwide. It offers proven insulating performance and excellent materials compatibility.
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
Honeywell Enovate® 245fa blowing agent (HFC-245fa) is a proven replacement for HCFC-141b and other hydrofluorocarbon and nonfluorocarbon blowing agents in rigid polyurethane foam.
Honeywell Enovate 245fa is:
Honeywell Enovate 245fa is:
- Non-ozone-depleting
- Nonflammable (ASTM E-681, EU A11)
- Listed under the U.S. EPA’s Significant New Alternatives Policy (SNAP) program to replace ozone-depleting substances. (See the Environmental tab for more information)
- Listed on the TSCA inventory/registered under REACH
- VOC-exempt (per U.S. EPA)
- Manufactured in the U.S.
Specifications
General Information
- Application
- Liquified Natural Gas (LNG)
- PUR/PIR Foams
- Panels/Boardstock
- Refrigerator/Freezer Insulation
- Spray Foam Insulation
- Brand
- Enovate®
- Formula
- CF<sub>3</sub>CH<sub>2</sub>CHF<sub>2</sub>
- Linear Formula
- CF3CH2CHF2
- Replaces
- Other HFCs, HCFCs
Physical Properties
- Liquid Density
- 1.32 g/cc at 20°C
- Molecular Weight
- 134
- Solubility in Water
- 1600 ppm
- Vapor Pressure
- 123 kPa at 20 °C hectopascal
- 17.8 psia at 68 °F hectopascal
- Vapor Thermal Conductivity
- 0.0832 BTU in/ft2 hr at 25 °C
- 12.5 mW/mK at 25
Temperature
- Boiling Point/Range
- 15.3 °C
- 59.5°F
- Flashpoint
- None
- Freezing Point
- <-107 °C
- <-160 °F
Safety & Environment
- Flammable Range
- Non-flammable
- Global Warming Potential
- 858
- Ozone Depletion Potential
- 0
Standards & Approvals
- REACH Product Stewardship
- Registered
General Information
- Application
- Liquified Natural Gas (LNG)
- PUR/PIR Foams
- Panels/Boardstock
- Refrigerator/Freezer Insulation
- Spray Foam Insulation
- Brand
- Enovate®
- Formula
- CF<sub>3</sub>CH<sub>2</sub>CHF<sub>2</sub>
- Linear Formula
- CF3CH2CHF2
- Replaces
- Other HFCs, HCFCs
Physical Properties
- Liquid Density
- 1.32 g/cc at 20°C
- Molecular Weight
- 134
- Solubility in Water
- 1600 ppm
- Vapor Pressure
- 123 kPa at 20 °C hectopascal
- 17.8 psia at 68 °F hectopascal
- Vapor Thermal Conductivity
- 0.0832 BTU in/ft2 hr at 25 °C
- 12.5 mW/mK at 25
Temperature
- Boiling Point/Range
- 15.3 °C
- 59.5°F
- Flashpoint
- None
- Freezing Point
- <-107 °C
- <-160 °F
Safety & Environment
- Flammable Range
- Non-flammable
- Global Warming Potential
- 858
- Ozone Depletion Potential
- 0
Standards & Approvals
- REACH Product Stewardship
- Registered
- Formula : CF3CH2CHF2
- Application : Liquified Natural Gas (LNG)|PUR/PIR Foams|Panels/Boardstock|Refrigerator/Freezer Insulation|Spray Foam Insulation
- Replaces : Other HFCs, HCFCs
- Linear Formula : CF3CH2CHF2
- Brand : Enovate®
- Vapor Thermal Conductivity : 0.0832 BTU in/ft2 hr at 25 °C|12.5 mW/mK at 25
- Liquid Density : 1.32 g/cc at 20°C
- Vapor Pressure : 123 kPa at 20 °C hectopascal|17.8 psia at 68 °F hectopascal
- Molecular Weight : 134
- Solubility in Water : 1600 ppm
- Freezing Point : <-107 °C|<-160 °F
- Boiling Point/Range : 15.3 °C|59.5°F
- Flashpoint : None
- Flammable Range : Non-flammable
- Global Warming Potential : 858
- Ozone Depletion Potential : 0
- REACH Product Stewardship : Registered
