HydroBlock®
HydroBlock P3000HS
HydroBlock® P-Series HS film is a polychlorotrifluoroethylene (PCTFE) copolymer film. It has the ability to heat seal to itself utilizing impulse sealing methods.
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
Specifications
General Information
- Application
- Sealing
- Performance Function
- Heat Sealing to Self
- Product Family
- P-Series HS Film
MD / TD
- Dimensional Stability
- ≤ +8%/≤ -8%
- Elongation
- 150 - 225%/200 - 250%
- Modulus, Secant
- 150,000 - 200,000 psi/150,000 - 200,000 psi
- Tear Strength, Graves
- 2.8 lbf/2.8 lbf
- Tensile Strength
- 8,000 - 10,000 psi/5,000 - 7,000 psi
Physical Properties
- Crystalline Melting Point
- 374°F
- Haze
- <1%
- Thickness (mm)
- 3
- Water Vapor Transmission Rate
- 0.010 gms/100in2/day
- Yield
- 4,432 in2/lb
Sampling
- Sample Products
- Yes
General Information
- Application
- Sealing
- Performance Function
- Heat Sealing to Self
- Product Family
- P-Series HS Film
MD / TD
- Dimensional Stability
- ≤ +8%/≤ -8%
- Elongation
- 150 - 225%/200 - 250%
- Modulus, Secant
- 150,000 - 200,000 psi/150,000 - 200,000 psi
- Tear Strength, Graves
- 2.8 lbf/2.8 lbf
- Tensile Strength
- 8,000 - 10,000 psi/5,000 - 7,000 psi
Physical Properties
- Crystalline Melting Point
- 374°F
- Haze
- <1%
- Thickness (mm)
- 3
- Water Vapor Transmission Rate
- 0.010 gms/100in2/day
- Yield
- 4,432 in2/lb
Sampling
- Sample Products
- Yes
- Application : Sealing
- Product Family : P-Series HS Film
- Performance Function : Heat Sealing to Self
- Tensile Strength : 8,000 - 10,000 psi/5,000 - 7,000 psi
- Tear Strength, Graves : 2.8 lbf/2.8 lbf
- Modulus, Secant : 150,000 - 200,000 psi/150,000 - 200,000 psi
- Elongation : 150 - 225%/200 - 250%
- Dimensional Stability : ≤ +8%/≤ -8%
- Yield : 4,432 in2/lb
- Water Vapor Transmission Rate : 0.010 gms/100in2/day
- Thickness (mm) : 3
- Haze : <1%
- Crystalline Melting Point : 374°F
- Sample Products : Yes
Data Sheet
Name
Description
File Size
Date
Size
HydroBlock P-Series HS Film
application/pdf 90.26 KB
10/31/2023
90.26 KB
