Powder Flux

Cesium tetrafluoroaluminate (01799)

special type, for brazing flux applications, melting point onset ≤445°C, particle size (D50) 5 – 20µm, assay of Cs (calc.to dried s.) 58 - 62%

Overview
Cesium Tetrafluoroaluminate Special processed powder for flux cored wires or rings and Cs-paste with water as solvent; , melting point onset max 445°C, assay of Cs (calc.to dried s.) 58 - 62%
Specifications

General Information

  • Application
    • Brazing
  • CAS Number
    • 138577-01-2
  • EC Number
    • 138577-01-2
  • Linear Formula
    • CsAlF4
  • Particle Texture/Size
    • Special
  • Product Type
    • Substance Degrees Celsius
  • Synonyms
    • (T-4)- (9CI)
    • Aluminate(1-)
    • Aluminium cesium fluoride
    • Cesium (T-4)-fluoroaluminate(1-)
    • Cesium aluminium fluoride
    • Cesium fluoroaluminate complex
    • cesium
    • cesium fluoroaluminate
    • fluoro-
  • Typical Uses
    • Joining aluminum alloys

Physical Properties

  • Boiling Point/Range
    • >500 °C
  • Chemical Composition
    • Aluminum cesium fluoride (UVCB)
  • Color
    • Colorless
  • Density
    • 3.74 g/cm3 (20 °C)
  • Flashpoint
    • Not applicable
  • Odor
    • Odorless
  • Particle Size Distribution
    • D50 - 5-20
  • Partition Coefficient
    • No data available
  • pH
    • 6 to 8 at 100 g/l (20 °C) Suspension
  • Physical Form
    • Powder
  • Solubility
    • 19.1 g/l (22 °C)
  • Solubility in Water
    • 19.1 g/l (22 °C)
  • Vapor Pressure
    • Negligible hectopascal

Safety Information

  • Chemical Stability
    • Stable under recommended storage conditions
  • Flammability
    • The product is not flammable
  • Flammable Gas Formation
    • The substance or mixture does not emit flammable gases in contact with water
  • Ignition Temperature
    • Not applicable
  • Incompatible Materials
    • Contact with strong acids liberates hydrogen fluoride
  • Oxidizing
    • The substance or mixture is not classified as oxidizing
  • Self Ignition
    • Not auto-flammable
  • Thermal Decomposition
    • Decomposition: 500 °C

International Transportation

  • Harmonized System Code
    • 3810100000

General Information

  • Application
    • Brazing
  • CAS Number
    • 138577-01-2
  • EC Number
    • 138577-01-2
  • Linear Formula
    • CsAlF4
  • Particle Texture/Size
    • Special
  • Product Type
    • Substance Degrees Celsius
  • Synonyms
    • (T-4)- (9CI)
    • Aluminate(1-)
    • Aluminium cesium fluoride
    • Cesium (T-4)-fluoroaluminate(1-)
    • Cesium aluminium fluoride
    • Cesium fluoroaluminate complex
    • cesium
    • cesium fluoroaluminate
    • fluoro-
  • Typical Uses
    • Joining aluminum alloys

Physical Properties

  • Boiling Point/Range
    • >500 °C
  • Chemical Composition
    • Aluminum cesium fluoride (UVCB)
  • Color
    • Colorless
  • Density
    • 3.74 g/cm3 (20 °C)
  • Flashpoint
    • Not applicable
  • Odor
    • Odorless
  • Particle Size Distribution
    • D50 - 5-20
  • Partition Coefficient
    • No data available
  • pH
    • 6 to 8 at 100 g/l (20 °C) Suspension
  • Physical Form
    • Powder
  • Solubility
    • 19.1 g/l (22 °C)
  • Solubility in Water
    • 19.1 g/l (22 °C)
  • Vapor Pressure
    • Negligible hectopascal

Safety Information

  • Chemical Stability
    • Stable under recommended storage conditions
  • Flammability
    • The product is not flammable
  • Flammable Gas Formation
    • The substance or mixture does not emit flammable gases in contact with water
  • Ignition Temperature
    • Not applicable
  • Incompatible Materials
    • Contact with strong acids liberates hydrogen fluoride
  • Oxidizing
    • The substance or mixture is not classified as oxidizing
  • Self Ignition
    • Not auto-flammable
  • Thermal Decomposition
    • Decomposition: 500 °C

International Transportation

  • Harmonized System Code
    • 3810100000
  • Product Type : Substance Degrees Celsius
  • EC Number : 138577-01-2
  • Particle Texture/Size : Special
  • CAS Number : 138577-01-2
  • Linear Formula : CsAlF4
  • Typical Uses : Joining aluminum alloys
  • Application : Brazing
  • Synonyms : (T-4)- (9CI)|Aluminate(1-)|Aluminium cesium fluoride|Cesium (T-4)-fluoroaluminate(1-)|Cesium aluminium fluoride|Cesium fluoroaluminate complex|cesium|cesium fluoroaluminate|fluoro-
  • Physical Form : Powder
  • Vapor Pressure : Negligible hectopascal
  • Boiling Point/Range : >500 °C
  • Solubility in Water : 19.1 g/l (22 °C)
  • Odor : Odorless
  • Particle Size Distribution : D50 - 5-20
  • Flashpoint : Not applicable
  • Chemical Composition : Aluminum cesium fluoride (UVCB)
  • Solubility : 19.1 g/l (22 °C)
  • Color : Colorless
  • Partition Coefficient : No data available
  • pH : 6 to 8 at 100 g/l (20 °C) Suspension
  • Density : 3.74 g/cm3 (20 °C)
  • Thermal Decomposition : Decomposition: 500 °C
  • Chemical Stability : Stable under recommended storage conditions
  • Flammability : The product is not flammable
  • Flammable Gas Formation : The substance or mixture does not emit flammable gases in contact with water
  • Incompatible Materials : Contact with strong acids liberates hydrogen fluoride
  • Self Ignition : Not auto-flammable
  • Oxidizing : The substance or mixture is not classified as oxidizing
  • Ignition Temperature : Not applicable
  • Harmonized System Code : 3810100000
