Liquid Flux
Honeywell Flux 30KCs (01610)
Liquid paint flux formulation, cesium enhanced, for non-corrosive controlled atmosphere aluminium brazing (CAB)
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
Excellent debinding at low temperature, low VOC and NOx. Cesium enhanced for applications were magnesium-containing aluminium alloys are used.
Specifications
General Information
- Application
- Brazing
- Liquid Flux
- CAS Number
- No data available
- Linear Formula
- Cesium enhanced
- Potassium fluoroaluminate salt
- Product Type
- Liquid Paint Flux Degrees Celsius
- Synonyms
- Aluminum cesium fluoride
- Aluminum potassium fluoride
- Cesium aluminum fluoride
- Fluoroaluminate, cesium salt
- Fluoroaluminate, potassium salt
- Potassium aluminum fluoride
- Typical Uses
- Non-corrosive controlled atmosphere
Physical Properties
- Boiling Point/Range
- 100 °C (The information regarding the boiling point is that of the solvent)
- Color
- White
- Density
- 1.1 to 1.4 g/cm3 (20 °C)
- Formula
- K-Cs-Al-F
- Melting Point/Range
- < 570 °C (The information regarding melting point/freezing point are those of the pure substance)
- Odor
- Product Specific
- pH
- 5 to 7 (20 °C) as a dispersion, undiluted
- Physical Form
- Suspension (water-based)
- Product Chemistry
- Fluoroaluminate salt
- Solubility in Water
- Suspension (water-based)
- Vapor Pressure
- similar to water hectopascal
Safety Information
- Chemical Stability
- No data available
- Incompatible Materials
- Contact with strong acids liberates hydrogen fluoride
- Self Ignition
- Not auto-flammable
International Transportation
- Chemical Class
- No data available
General Information
- Application
- Brazing
- Liquid Flux
- CAS Number
- No data available
- Linear Formula
- Cesium enhanced
- Potassium fluoroaluminate salt
- Product Type
- Liquid Paint Flux Degrees Celsius
- Synonyms
- Aluminum cesium fluoride
- Aluminum potassium fluoride
- Cesium aluminum fluoride
- Fluoroaluminate, cesium salt
- Fluoroaluminate, potassium salt
- Potassium aluminum fluoride
- Typical Uses
- Non-corrosive controlled atmosphere
Physical Properties
- Boiling Point/Range
- 100 °C (The information regarding the boiling point is that of the solvent)
- Color
- White
- Density
- 1.1 to 1.4 g/cm3 (20 °C)
- Formula
- K-Cs-Al-F
- Melting Point/Range
- < 570 °C (The information regarding melting point/freezing point are those of the pure substance)
- Odor
- Product Specific
- pH
- 5 to 7 (20 °C) as a dispersion, undiluted
- Physical Form
- Suspension (water-based)
- Product Chemistry
- Fluoroaluminate salt
- Solubility in Water
- Suspension (water-based)
- Vapor Pressure
- similar to water hectopascal
Safety Information
- Chemical Stability
- No data available
- Incompatible Materials
- Contact with strong acids liberates hydrogen fluoride
- Self Ignition
- Not auto-flammable
International Transportation
- Chemical Class
- No data available
- Linear Formula : Cesium enhanced|Potassium fluoroaluminate salt
- Typical Uses : Non-corrosive controlled atmosphere
- Product Type : Liquid Paint Flux Degrees Celsius
- Application : Brazing|Liquid Flux
- CAS Number : No data available
- Synonyms : Aluminum cesium fluoride|Aluminum potassium fluoride|Cesium aluminum fluoride|Fluoroaluminate, cesium salt|Fluoroaluminate, potassium salt|Potassium aluminum fluoride
- pH : 5 to 7 (20 °C) as a dispersion, undiluted
- Solubility in Water : Suspension (water-based)
- Melting Point/Range : < 570 °C (The information regarding melting point/freezing point are those of the pure substance)
- Boiling Point/Range : 100 °C (The information regarding the boiling point is that of the solvent)
- Product Chemistry : Fluoroaluminate salt
- Vapor Pressure : similar to water hectopascal
- Physical Form : Suspension (water-based)
- Formula : K-Cs-Al-F
- Density : 1.1 to 1.4 g/cm3 (20 °C)
- Color : White
- Odor : Product Specific
- Incompatible Materials : Contact with strong acids liberates hydrogen fluoride
- Chemical Stability : No data available
- Self Ignition : Not auto-flammable
- Chemical Class : No data available
