Liquid Flux
Honeywell Paint Flux PFF 35 M 6.5 (01645)
Liquid paint flux formulation for non-corrosive controlled atmosphere aluminium brazing (CAB)
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
Enhanced adhesion, even on greasy surface. Well suited for applications were low magnesium containing alloys are used.
Specifications
General Information
- Application
- Brazing
- Liquid Flux
- CAS Number
- 55965-84-9
- Concentration
- 5- chloro-2-methyl-4- isothiazolin-3-one and 2-methyl-2H - isothiazol-3-one (3:1) - <= 0.0002 %
- Aluminum potassium fluoride - >= 25 % to < 50 %
- Linear Formula
- Not cesium enhanced
- Potassium fluoroaluminate salt
- Product Type
- Liquid Paint Flux Degrees Celsius
- Synonyms
- Aluminum potassium fluoride
- Fluoroaluminate
- Potassium aluminum fluoride
- Potassium salt
- Typical Uses
- Non-corrosive controlled atmosphere
Physical Properties
- Boiling Point/Range
- 100 °C (The information regarding the boiling point is that of the solvent)
- Chemical Composition
- 5- chloro-2-methyl-4- isothiazolin-3-one and 2-methyl-2H - isothiazol-3-one (3:1)
- Aluminum potassium fluoride
- Color
- White
- Density
- 1.1 to 1.4 g/cm3 (20 °C)
- Flashpoint
- Not determined
- Formula
- K-Al-F
- Melting Point/Range
- < 570 °C (The information regarding melting point/freezing point are those of the pure substance)
- Odor
- Product Specific
- Partition Coefficient
- Not applicable
- pH
- 5 to 7 (20 °C) as a dispersion, undiluted
- Physical Form
- Suspension (water-based)
- Product Chemistry
- Fluoroaluminate salt
- Solubility in Water
- Suspension (water-based)
- Vapor Pressure
- similar to water hectopascal
Safety Information
- Chemical Stability
- Stable under recommended storage conditions
- Corrosivity
- Corrosive to the respiratory tract
- Flammability
- Not applicable
- Ignition Temperature
- Not applicable
- Incompatible Materials
- Contact with strong acids liberates hydrogen fluoride
- Oxidizing
- Not oxidizing
- Self Ignition
- Not auto-flammable
- Thermal Decomposition
- Stable under recommended storage conditions
International Transportation
- Chemical Class
- No data available
- Harmonized System Code
- 3810905000
General Information
- Application
- Brazing
- Liquid Flux
- CAS Number
- 55965-84-9
- Concentration
- 5- chloro-2-methyl-4- isothiazolin-3-one and 2-methyl-2H - isothiazol-3-one (3:1) - <= 0.0002 %
- Aluminum potassium fluoride - >= 25 % to < 50 %
- Linear Formula
- Not cesium enhanced
- Potassium fluoroaluminate salt
- Product Type
- Liquid Paint Flux Degrees Celsius
- Synonyms
- Aluminum potassium fluoride
- Fluoroaluminate
- Potassium aluminum fluoride
- Potassium salt
- Typical Uses
- Non-corrosive controlled atmosphere
Physical Properties
- Boiling Point/Range
- 100 °C (The information regarding the boiling point is that of the solvent)
- Chemical Composition
- 5- chloro-2-methyl-4- isothiazolin-3-one and 2-methyl-2H - isothiazol-3-one (3:1)
- Aluminum potassium fluoride
- Color
- White
- Density
- 1.1 to 1.4 g/cm3 (20 °C)
- Flashpoint
- Not determined
- Formula
- K-Al-F
- Melting Point/Range
- < 570 °C (The information regarding melting point/freezing point are those of the pure substance)
- Odor
- Product Specific
- Partition Coefficient
- Not applicable
- pH
- 5 to 7 (20 °C) as a dispersion, undiluted
- Physical Form
- Suspension (water-based)
- Product Chemistry
- Fluoroaluminate salt
- Solubility in Water
- Suspension (water-based)
- Vapor Pressure
- similar to water hectopascal
Safety Information
- Chemical Stability
- Stable under recommended storage conditions
- Corrosivity
- Corrosive to the respiratory tract
- Flammability
- Not applicable
- Ignition Temperature
- Not applicable
- Incompatible Materials
- Contact with strong acids liberates hydrogen fluoride
- Oxidizing
- Not oxidizing
- Self Ignition
- Not auto-flammable
- Thermal Decomposition
- Stable under recommended storage conditions
International Transportation
- Chemical Class
- No data available
- Harmonized System Code
- 3810905000
