Liquid Flux
Honeywell Paint Flux PFF C50M 8,1 (01673)
Liquid paint flux formulation, cesium enhanced, for non-corrosive controlled atmosphere aluminium brazing (CAB)
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
Excellent debinding at low temperature, low VOC and NOx. Cesium enhanced for applications were magnesium-containing aluminium alloys are used.
Specifications
General Information
- Application
- Brazing
- Liquid Flux
- CAS Number
- 55965-84-9
- Concentration
- Aluminum cesium fluoride (UVCB) - < 10 %
- Aluminum potassium fluoride - >= 25 % to < 50 %
- reaction mass of: 5- chloro-2-methyl-4- isothiazolin-3-one and 2-methyl-2H - isothiazol-3-one (3:1) - < 0.0003 %
- EC Number
- 613-167-00-5
- Linear Formula
- Cesium enhanced
- Potassium fluoroaluminate salt
- Product Type
- Liquid Paint Flux Degrees Celsius
- Synonyms
- Aluminum cesium fluoride
- Aluminum potassium fluoride
- Cesium aluminum fluoride
- Fluoroaluminate, cesium salt
- Fluoroaluminate, potassium salt
- Potassium aluminum fluoride
- Typical Uses
- Non-corrosive controlled atmosphere
Physical Properties
- Boiling Point/Range
- 100 °C (The information regarding the boiling point is that of the solvent)
- Chemical Composition
- Aluminum cesium fluoride (UVCB)
- Aluminum potassium fluoride
- reaction mass of: 5- chloro-2-methyl-4- isothiazolin-3-one and 2-methyl-2H - isothiazol-3-one (3:1)
- Color
- White
- Density
- 1.1 to 1.4 g/cm3 (20 °C)
- Flashpoint
- Not applicable
- Formula
- K-Cs-Al-F
- Melting Point/Range
- < 570 °C (The information regarding melting point/freezing point are those of the pure substance)
- Odor
- Product Specific
- Partition Coefficient
- Not applicable
- pH
- 5 to 7 (20 °C) as a dispersion, undiluted
- Physical Form
- Suspension (water-based)
- Product Chemistry
- Fluoroaluminate salt
- Solubility in Water
- Suspension (water-based)
- Vapor Pressure
- similar to water hectopascal
Safety Information
- Chemical Stability
- Stable under recommended storage conditions.
- Corrosivity
- Corrosive to the respiratory tract
- Flammability
- Not applicable
- Ignition Temperature
- Not applicable
- Incompatible Materials
- Contact with strong acids liberates hydrogen fluoride
- Oxidizing
- The substance or mixture is not classified as oxidizing
- Self Ignition
- Not auto-flammable
- Thermal Decomposition
- Stable under recommended storage conditions
International Transportation
- Chemical Class
- No data available
- Harmonized System Code
- 38109090
General Information
- Application
- Brazing
- Liquid Flux
- CAS Number
- 55965-84-9
- Concentration
- Aluminum cesium fluoride (UVCB) - < 10 %
- Aluminum potassium fluoride - >= 25 % to < 50 %
- reaction mass of: 5- chloro-2-methyl-4- isothiazolin-3-one and 2-methyl-2H - isothiazol-3-one (3:1) - < 0.0003 %
- EC Number
- 613-167-00-5
- Linear Formula
- Cesium enhanced
- Potassium fluoroaluminate salt
- Product Type
- Liquid Paint Flux Degrees Celsius
- Synonyms
- Aluminum cesium fluoride
- Aluminum potassium fluoride
- Cesium aluminum fluoride
- Fluoroaluminate, cesium salt
- Fluoroaluminate, potassium salt
- Potassium aluminum fluoride
- Typical Uses
- Non-corrosive controlled atmosphere
Physical Properties
- Boiling Point/Range
- 100 °C (The information regarding the boiling point is that of the solvent)
- Chemical Composition
- Aluminum cesium fluoride (UVCB)
- Aluminum potassium fluoride
- reaction mass of: 5- chloro-2-methyl-4- isothiazolin-3-one and 2-methyl-2H - isothiazol-3-one (3:1)
- Color
- White
- Density
- 1.1 to 1.4 g/cm3 (20 °C)
- Flashpoint
- Not applicable
- Formula
- K-Cs-Al-F
- Melting Point/Range
- < 570 °C (The information regarding melting point/freezing point are those of the pure substance)
- Odor
- Product Specific
- Partition Coefficient
- Not applicable
- pH
- 5 to 7 (20 °C) as a dispersion, undiluted
- Physical Form
- Suspension (water-based)
- Product Chemistry
- Fluoroaluminate salt
- Solubility in Water
- Suspension (water-based)
- Vapor Pressure
- similar to water hectopascal
Safety Information
- Chemical Stability
- Stable under recommended storage conditions.
- Corrosivity
- Corrosive to the respiratory tract
- Flammability
- Not applicable
- Ignition Temperature
- Not applicable
- Incompatible Materials
- Contact with strong acids liberates hydrogen fluoride
- Oxidizing
- The substance or mixture is not classified as oxidizing
- Self Ignition
- Not auto-flammable
- Thermal Decomposition
- Stable under recommended storage conditions
International Transportation
- Chemical Class
- No data available
- Harmonized System Code
- 38109090
- Linear Formula : Cesium enhanced|Potassium fluoroaluminate salt
- Concentration : Aluminum cesium fluoride (UVCB) - < 10 %|Aluminum potassium fluoride - >= 25 % to < 50 %|reaction mass of: 5- chloro-2-methyl-4- isothiazolin-3-one and 2-methyl-2H - isothiazol-3-one (3:1) - < 0.0003 %
- Typical Uses : Non-corrosive controlled atmosphere
- Product Type : Liquid Paint Flux Degrees Celsius
- Application : Brazing|Liquid Flux
- CAS Number : 55965-84-9
- EC Number : 613-167-00-5
- Synonyms : Aluminum cesium fluoride|Aluminum potassium fluoride|Cesium aluminum fluoride|Fluoroaluminate, cesium salt|Fluoroaluminate, potassium salt|Potassium aluminum fluoride
- pH : 5 to 7 (20 °C) as a dispersion, undiluted
- Partition Coefficient : Not applicable
- Chemical Composition : Aluminum cesium fluoride (UVCB)|Aluminum potassium fluoride|reaction mass of: 5- chloro-2-methyl-4- isothiazolin-3-one and 2-methyl-2H - isothiazol-3-one (3:1)
- Solubility in Water : Suspension (water-based)
- Melting Point/Range : < 570 °C (The information regarding melting point/freezing point are those of the pure substance)
- Boiling Point/Range : 100 °C (The information regarding the boiling point is that of the solvent)
- Product Chemistry : Fluoroaluminate salt
- Vapor Pressure : similar to water hectopascal
- Physical Form : Suspension (water-based)
- Flashpoint : Not applicable
- Formula : K-Cs-Al-F
- Density : 1.1 to 1.4 g/cm3 (20 °C)
- Color : White
- Odor : Product Specific
- Incompatible Materials : Contact with strong acids liberates hydrogen fluoride
- Thermal Decomposition : Stable under recommended storage conditions
- Ignition Temperature : Not applicable
- Chemical Stability : Stable under recommended storage conditions.
- Self Ignition : Not auto-flammable
- Flammability : Not applicable
- Corrosivity : Corrosive to the respiratory tract
- Oxidizing : The substance or mixture is not classified as oxidizing
- Harmonized System Code : 38109090
- Chemical Class : No data available
